    1R1G1B Outdoor Fixed LED Number Display IP65 P4 With S - Video VGA DVI Input

    Ask Lasest Price
    Brand Name : Shenzhen LED World
    Model Number : LW-FO 20
    Certification : CE,RoHS,FCC,CCC
    Price : negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 5,000 square meters per month
    Delivery Time : 10~20 days after receiving the deposit
    • Product Details
    • Company Profile

    1R1G1B Outdoor Fixed LED Number Display IP65 P4 With S - Video VGA DVI Input


    Professional IP65 Outdoor Fixed LED Number Display P4 With S-Video VGA DVI Input

    Quick detail:

    • Improved Picture Quality Clarity;
    • Refresh rate ranging from 1920HZ to 3840HZ, no ghost;
    • High contrast, high refresh rate make the image without any delay, trailing smear;
    • Other available LED lamp option: Nationstar, San’an. Available IC: Sunmoon;
    • Synchronously adjust the brightness and color to make the true and exquisite image;
    • Using Kinglight LED lamp and Macroblock 5124 IC;
    • Wide color range, excellent color uniformity;


    Product parameters:

    P4 outdoor fixed led display
    Module Parameter
    Pixel pitch4mm
    Pixel Density62500 pixels/sqm.
    LED typeSMD1921 black
    Pixel combination1R1G1B
    Module size320x160mm
    Module resolution80x40 pixels
    Driving mode1/10 scan
    Panel Parameter
    Number of modules2W*4H
    Panel size640x640mm
    Panel resolution160x160
    Maintain wayRear
    IP RatingIP65
    Flatness≤0.1mm
    Cabinet materialDie-cast aluminium or Iron
    General Parameter
    Viewing distance≥5M
    Brightness≥6500CD/sqm.
    Viewing angle120°/120°
    Weight40kg/sqm.
    Max Power consumption900W/sqm.
    Aver Power consumption360W/sqm.
    Frame frequency≥60HZ
    Refresh frequency≥1920HZ
    Working Temperature-30ºC~50ºC
    Working VoltageAC90~260V±20%,50-60HZ
    Grey scale/color16384x16384x16384
    Brightness adjustment0-255
    MTBF5000 hours
    Life100000 hours
    Malfunction dot rate<0.0001
    Control distanceEthernet cable≤100m, Single mode fiber optic ≤500m, Multimode fiber optic ≤15km
    Control system
    Control systemNovastar / Linsn / Colorlight ( Optional )
    Input signalDVI / HDMI / SDI / VGA / S-video / Composite
    Video processorVDWALL / RGBlingk / Novastar ( Optional )
    Audio system
    Audio systemBOSE / JBL / PAL / Customized ( Optional )
    InstallationFixed installation / Rental installation ( Optional )
    Hanging barOptional
    CertificationCE / RoHS / ETL / CCC / FCC / BS476
    Packing TypePlywood case / Flight case ( Optional )
    Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.


    FQA:

    1. What is a pixel?
    The minimum luminous pixel LED display, with ordinary computer monitor, said the "pixel" the same meaning;
    2. How to deal with the faulty?
    Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%;Secondly, during the guarantee period, we will send new module with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
    3. How many workers do you have now?
    We have 200 employees.
    4. Can you offer a technical support ? Since it s my first time.... ?
    We provide free training for our customer, teach client how to set up screens, make configuration of parameters, broadcast the videos through Nova star or Linsn control systems, configure of video processor of LVP605s,LED-550DS.
    5. Can I use my own forwarder to transport the products for me?
    Yes, if you have your own forwarder in Guangzhou, you canletyour forwardership the products for you. And then you will no need to pay the freight to us;


    Product case:
