| Brand Name : | Shenzhen LED World |
| Model Number : | LW-FO 6 |
| Certification : | CE,RoHS,FCC,CCC |
| Price : | negotiable |
| Payment Terms : | T/T, Western Union, MoneyGram |
| Supply Ability : | 5,000 square meters per month |
| Delivery Time : | 10~20 days after receiving the deposit |
High brightness 6mm pixel pitch DIP led display fixed outdoor video wall billboard
Features:
Parameter:
| The specifications of modules | |
| Items | Parameter |
| Product Model | P6 Outdoor DIP LED Display |
| Module size | 192mm*192mm |
| Pixel pitch | 6mm |
| Pixel density | 27777dots/m2 |
| Pixel configuration | 1R1G1B |
| Module resolution | 32dots(W)*16dots |
| Module maximum power consumption | 20W |
| Module Thickness | 2.7CM |
| Module Weight | 0.4kg |
| Driving method | Constant Current Driving |
| Scanning method | 1/8scan |
| Interface | HUB75 |
| Brightness | ≥7000cd/m2 |
| The specifications of cabinets | |
| Cabinet size | 768mm*768mm |
| Module quantity | 32pcs |
| Power supply | 5V/40A 5V/60A |
| Cabinet resolution | 128*128dots |
| Optimal viewing distance | 5M~50M |
| Optimal viewing angle | 160°(W) 120°(H) |
| RHWorking temperature | (Work :-20°C~+60°C) |
| System operating humility | 10%-95% |
| The specifications of power supplier | |
| Operating Voltage | AC220V±10% |
| Average power consumption | 350W/H |
| Maximum power consumption | ≤600W/m2 |
| Electric current | ≤20mA(single LED) |
| The specifications of control card | |
| Control Panels | Pentium4 or above |
| Operating system | WIN98/2000/NT/XP |
| Control model | Synchronization with PC |
| The specifications of the main technical parameters | |
| Driving device | Constant Current Driving |
| Refresh rate | ≥600HZ |
| Grey scale | RGB Each 256, can display 16.7M colors) |
| MTBF | ≥9000hours |
| Power switch | Automatic Switch |
| Display Mode | 800*600/1024*768/1280*900 |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | |
Why choose us:
Our company:
Shenzhen LED World co.,ltd is a professional LED media/video
display manufacturer.
LED WORLD also has got good reputation from different users, our
products are mainly supplied for international market, so offering
quality products, competitive price, our enterprise survival in the
big market. At any time,we are the best one of your reliable
choice.
Main markets in North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western
Europe, has set up stable sales agents in the corresponding areas.
Our company offers user-friendly products that optimize
productivity and business efficiency and maintain the highest
standards of design and quality.
Product detail:


|
