    P12 MBI5024GF drviing IC high brightness led screen display with 192x192 mm modules

    Ask Lasest Price
    Brand Name : Shenzhen LED World
    Model Number : LW-FI 12
    Certification : RoHS,FCC,CCC,CE
    Price : negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 2000 square meter /Month
    Delivery Time : 12~18 days after receiving the deposit
    • Product Details
    • Company Profile

    P12 MBI5024GF drviing IC high brightness led screen display with 192x192 mm modules

    Indoor fixed led display_201905211023311.pdf

    P12 MBI5024GF drviing IC high brightness led screen display with 192x192 mm modules

    P12 LED video wall features:

    • Large viewing angle, Up to 140° (Horizontal & Vertical) by using our own specially designed masks;
    • It is good high resolution LED display, indoor LED video wall, Indoor LED panel, Indoor LED wall ;
    • Quality insured by CPIC and 3-year QA;
    • Low power consumption and good performance of dissipating heat make it work normally in the condition of no air conditioning;
    • adopt efficient optical fiber transmission system, effectively reduce the signal delay phenomenon, to assure the consistence of part of the game screen showing;
    • High contrast,ideal gray scale,presenting the clear and bright pictures;
    • Video, flash, animation, graphic, text available;
    • Long Lifespan
    • LED world chooses high quality components patent circuit board design for display to ensure the using-life;

    P12 indoor fixed LED screens application:

    Our full color LED display are widely used in hotel,TV-Show,large entertainment plaza,conference video center, internal,plaza,telecommunications,bar,Government facilities,meeting rooms,touring,Convenience Stores,airport,stadium and so on .


    P12 indoor fixed LED signs parameter:

    Specification of Indoor SMD 3-in-1 LED Display
     P12
    Pixel pitch12mm
    Size of module192×192mm
    Density of pixel6944dots/m2
    Constitution1R1G1B
    Encapsulation3528
    Module resolution16×16
    Module power cosumption35W
    The optimum viewing distance10m
    Viewing angle(Horizontal)120°
    Maximum power cosumption800W/m2
    size of cabinet768×576 mm
    Resolution of cabinet64×48
    Cabinet weight43kg
    Driving ComponentsMBI5024GF
    Driving method1/4
    Frame frequency≥60hz/s
    Refresh rate≥400hz/s
    Luminance of white balance≥1100 CD/m2
    Working enviornment temperature-10ºC--50ºC(-30ºC--50ºCoptional)
    Working voltage220±10% or 110±10%
    Grey Scale/ColorDisplaying colors≥16.7M(synchronized)
    Brightness adjustment256 levels of each color(R,G,B) can be adjusted manually, and 8 levels of each color can be adjusted automatically
    Input signalRF, S-VIDEO, RGB, RGBHV, YUV, YC and COMPOSITION, etc
    Control systemPCTV non-linear editting card+DVI display card+main controller card+optic fibre transmission(Optional)
    Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

    Our service:

    • Customer can send your engineer who has electronic and computer knowledge to our factory for the operation and maintenance training;
    • Protection of your sales area, ideas of design and all your private information;
    • On-line remote service is available;
    • Service time: 24 hours*7 days;

    P12 indoor fixed LED screen product package:
