    Light Weight Waterproof Ip65 P5 Led Panel Video For Fixed Installation

    Ask Lasest Price
    Brand Name : Shenzhen LED World
    Model Number : LW-FO 5
    Certification : CE,RoHS,FCC,CCC
    Price : negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 5,000 square meters per month
    Delivery Time : 10~20 days after receiving the deposit
    • Product Details
    • Company Profile

    Light Weight Waterproof Ip65 P5 Led Panel Video For Fixed Installation

    Outdoor series fixed led display_201905211506521.p...

    Waterproof IP65 P5 outdoor display LED screen for fixed installation


    P5 outdoor fixed LED display features:

    • Special power supplier can save 20% the space, the range of voltage fluctuation is 5% less, high stability;
    • The screen displays delicate and vivid pictures through synchronous adjustment of color and brightness;
    • Muti-layer circuit PCB,uniform current distribution,low power consumption,fast heat dissipation,prolong the life of the screen;
    • Professional aviation packaging protects the control equipment well;
    • widely used in building showing;
    • Display Color: 256*256*256;
    • with IP65 protection grade, fear any bad weather;

    Outdoor 5mm pixel pitch led panel parameter:

    ModuleParameter NO.P5
    Size of Module(mm)320*160
    Pixel Density(dots/m²)40000 dots/m²
    Pixel Pitch(mm)5mm
    LED EncapulationSMD2727
    Resolution of Module(dots)64(W)*32(H)
    Thickness of Module (mm)17.05(No magnet)
    Weight of Module (Kg)0.5
    Driving MethodConstant Current Driving
    Equilibrium Brightness(CD//m²)≥6000 CD/m²
    BracketSize(mm)160*160
    320*160
    CabinetSize of Cabinet(mm)960*960
    Power Supply Mode5V/60A*3PC
    Best Viewing Distance(m)5-100m
    Best Viewing Angle160(W) 120(H)
    Storage Temperature(ºC)-35ºC ~ +85ºC
    Working Temperature(ºC)-40ºC ~ +50ºC
    Relative Humidity10%-95%
    Power SupplyWorking Voltage(V)AC220V±10%
    Average Power Consumption(W/m²)≤500 W/m²
    Max Consumption(W/m²)≤1000 W/m²
    Control SystemScan and control Method1/8 Synchronous Control
    Driving ComponentsConstant current Driving
    Technical ParametersRefresh Frequency≥1920 Hz/Sec
    (HZ)

    Frame Frequency≥60 HZ/Sec
    (HZ)
    Level of Brightness/ColorRGB256
    Level of Gray65536
    Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

    Our company:

    top 3 among same-grade manufacturers in China.
    Our company specializes in LED displays, including LED display rental series, LED display fixed seried,curtain led display series, adverting projects series, and so on.
    Through the efforts and collaboration of all employees of the company, the products are exported to Europe, North America, Australia, the Middle East, and the establishment of a stable distribution agents in the respective regions.


    FQA:

    • Can it play HD video?
    • Yes, it can realize HD video function with Linsn/nova controlling system;
    • Where is your company?
    • We are located in address:No.4 Bldg,Second Industrial Park of Baiwang,Baimang Village,Xili street,Nanshan District,Shenzhen,China;
    • May I know the Minimum order for your products?
    • For our products, no limit for the size of the screen, but generally speaking, one screen the dots more than 50000 dots will be clear for the audience to see the video on the screen;
